Description
This is a E-T-A 1 Pole 15A 250VAC 28VDC Thermal Circuit Breaker. Its part number is 2-5700-IG1-P10. This is a single pole thermal circuit breaker with press-to-reset, tease-free, trip-free, snap action mechanism this is a push-push switch/circuit breaker.
It comes as pictured and does not include any additional parts or accessories.
Specifications:
- Manufacturer: E-T-A
- Part Number: 2-5700-IG1-P10
- Breaker Type: Thermal
- Current Rating (Amps): 15A
- Voltage Rating - AC: 250V
- Voltage Rating - DC: 50V
- Number of Poles: 1
- Actuator Type: Push-Push
- Mounting Type: Panel Mount
Typical applications:
- Motors, transformers, solenoids, battery chargers, power supplies, appliances, machinery, extra low voltage systems.
