Description
MICRO SWITCH CPS Series Cable-Pull Safety Switches provide a readily accessible emergency stop signal, a cost-effective means compared to using multiple emergency stop push-buttons. The CPS Series Cable Pull Safety Switch’s internal mechanism latches on both slackened cable (push) and pulled cable.
This item comes as pictured and does not include any additional parts or accessories.
Specifications:
- Manufacturer: Honeywell
- Part Number: 2CPSA2A1B
- Material: Zinc Die-Cast
- Voltage Rating: 300 VAC
- IP Rating: IP67
- Actuator Type: Turnbuckle
- Operation: Latched when tripped from either direction
- Current Rating: 10 A
- Function: Safety
- Special Features: Indicator light: 120V LED cluster
- NEMA Rating: 1, 12, 13, 4
- Series: 2CPS Series
- Standards: BG, UL, CSA, CE Approved
- Contact Form: DPST-NC + DPST-NO
Application:
- Long conveyor systems found in warehouses and distribution centers, Conveyor systems having a high amount of vibration, Conveyor systems that experience wide temperature swings.
