Description
This is an HPE StoreFabric SN6600B 32Gb 48/48 Power Pack+ Fibre Channel Switch - Switch - managed - 48 x SFP+ + 4 x QSFP+ - rack-mountable. Its part number is Q0U57B.
This item comes as pictured and does not include any additional parts or accessories.
Specifications:
- Manufacture: HPE
- Part Number: Q0U57B
- Device Type: Switch - 48 ports - managed
- Enclosure Type: Rack-mountable 1U
- Subtype: Fibre Channel
- Ports: 48 x SFP+ + 4 x QSFP+
- Aggregate bandwidth: 2 Tbps , Port-to-port latency: 700 ns
- Capacity: Maximum frame size: 2112
- Remote Management Protocol: SNMP 1, SNMP 3, HTTP, SMI-S, SSH, CLI, HTTPS, SSH-2Encryption Algorithm: SSLAuthentication Method: DH-CHAP, FCAP, LDAP, RADIUS, TACACS+Features: ISL support, Syslog support, manageable, RBAC, SCP, SFTP client, SFTP server, QoS, FPI monitoring, SDDQ, DFP, DPS, Enhanced BB Credit Recovery, FDMI, FSPF, ISL Trunking, RSCN support, RCS, SNS
- Interfaces: 48 x 32Gb Fibre Channel SFP+ ¦ 4 x 32Gb Fibre Channel QSFP+ ,1 x 100Base-TX management , 1 x console management , 1 x USB
- Power Device: Internal power supply - hot-plug
- Installed Qty: 2
- Max Supported Qty: 2
- Power Redundancy: Yes
- Power Redundancy Scheme: 1+1
- Voltage Required: AC 120/230 V (50/60 Hz)
- Operating Temperature: 32 °F
- Max Operating Temperature: 104 °F
- Humidity Range Operating: 10 - 85% (non-condensing)
- Min Storage Temperature: -13 °F
- Max Storage Temperature: 158 °F
- Width: 17.3 in
- Depth: 14 in
- Height: 1.7 in
- Weight: 17.04 lbs
Box includes:
- 1 - HPE SN6600B 32GB 48/48 Power Pack Fibre Channel Switch Part # Q0U57B
- 48 - HPE 16Gb SW B-series SFP+ Transceivers Part # QK724A
- 1 - Rack Mounting Kit
- 1 - Serial cable
- 2 - Power Cables
The HP Q0U57B includes the full Power Pack+ software bundle as a standard feature. This bundle includes various advanced features and licenses such as:
- Advanced Performance Monitoring (APM)
- Fabric Watch
- ISL (Inter-Switch Link) Trunking
- Advanced Zoning
- Integrated Routing (optional license, but generally part of the pack functionality)
