Description
This item is a SKF P2BTC 40M-CPSS-DFH Short Base Pillow Block Ball Bearing Unit. Its part number is 40M-CPSS-DFH.
Short base pillow block ball bearing units consist of an insert bearing mounted in a composite housing. It has threads for attachment bolts and is suitable for applications with both constant and alternating directions of rotation. It has a narrow inner ring and is locked onto the shaft by tightening a set screw on the inner ring, making it easy to mount.
This item comes as pictured and does not include any additional parts or accessories.
Specifications:
- Manufacturer: SKF
- Part Number: 40M-CPSS-DFH
- Product: Pillow Block Ball Bearing Unit
- Shaft Diameter: 40mm
- Center Height (Pillow Block): 49.2mm
- Housing Overall Width: 33mm
- Center Distance Between Bolt Holes: 89mm
- Bearing Width (Total): 40.7mm
- Housing Type: Pillow Block
- Number of Bolt Holes for Fasteners: 2
- Fastening Bolt Hole Type: Threaded
- Retaining Feature (Inner Ring): Set Screws
- Bore Type: Cylindrical
- Sealing Type: Contact, Gutter
- Sealing Unit: End Cover and Back Seal
- Lubricant: Grease
